PITCH BLACK Y70 TOUCH INFINITE

Product Features

Fascinating 14.9″ Integrated IPS Touch Screen

With a resolution of 682 x 2560 (2.5K) and a 60Hz refresh rate, this capacitive IPS touchscreen delivers an incredibly sharp and smooth visual experience like the 10-point multi-touch butter, unlocking a wealth of possibilities and ample screen customization powered by the HYTE Nexus software. Our 3rd generation panel, larger and brighter, features a larger 14.9″ display with 43% more brightness for a more immersive user experience. All in one package integrated into the chassis structure of the box, pioneer in significant digital interaction with the best screen ever seen in a box.

4 Slots Massive Vertical Graphics

The Y70 extends the GPU support to 4 slots with additional space for airflow between the edge of the card and the glass. This means you can install even the largest and most powerful graphics cards in your construction smoothly. In addition, cooling on the lower floor can house up to three 120 mm fans or two 140 mm fans up to 32 mm thick to direct the flow of fresh air directly to the GPU.

Luxury PCIE 4.0 lift cable included

The case includes a 4.0 x 16 luxury PCIE elevator with a similar color canopy for an uninterrupted visual flow that will make the GPU installation and construction process painless. It also allows a large number of medium-height PCIE cards to be placed behind the throne of vertical graphics.

Huge cooling capacity

A spacious interior offers space for a radiator up to 360 mm in length and 125 mm thick on the side, and an adjustable upper support that can house another 360 mm radiator up to 68 mm thick. Working along with cooling in the cold floor at the bottom and a place for an additional fan at the rear of the case, the Y70 has a total capacity of 10 fans in a fully populated chassis. With more than 180 mm of free space towards the side glass, both air and water cooling enthusiasts will appreciate the flexibility the chassis gives them to create the most robust cooling configurations possible.

Unified modern aesthetics

With 4 unique colors, the Y70 puts your construction in the foreground with a beautifully designed 3-piece panoramic glass, which serves as a window to the heart of your PC. The dual-chamber interior design keeps the front looking great while giving you plenty of space to manage the cables on the back, especially with the help of our seamless L-shaped molded rubber gasket, meticulously placed cable routing channels, fastening points and reusable Velcro straps. All of this is easily accessible with top and side panels without tools, along with floating storage trays that are ejected from the back of the case for easy maintenance of the units.

TECH SPECS

Type Double Camera Medium Tower ATX Box Exterior Dimensions 470 x 320 x 470 mm
Volume (L) 70.7 Base plate sizes ITX, mATX, ATX, EATX
Expansion Slots 7 stockings + 4 full height Elevator cable included Yes, PCIE 4.0 x 16
I/S 1 USB-C 3.2 2nd generation, 2 USB-A 3.2 1.2 1.2th generation, 1 3.5 mm combined audio/microphone connector Dust filters Up, Side, Down
Best Fans 3x 120 mm / 2x 140 mm Upper Radiator 120-360, 140-280 @ 68 mm thick
Rear fans 1x 120/140 mm Rear radiator 1x 120/140 mm
Side fans 3x 120 mm / 2x 140 mm Side Radiator 120-360, 140-280 @ 125 mm thick
Background fans 3x 120 mm / 2x 140 mm @ 32 mm thick Maximum length of video card 422 mm
Maximum Video Card Thickness 105 mm Maximum CPU Cooler Height 180 mm
Maximum power supply length 235 mm Storage 2 3.5″ or 4 2.5″ SSDs
Guarantee 4 Years SKU (touch) CS-HYTE-Y70TTI-WW / CS-HYTE-Y70TTI-WB / CS-HYTE-Y70TTI-BB / CS-HYTE-Y70TTI-RB

Technical specifications for touch screen

Panel technology IPS Screen size (diagonal) 14.9 inches
Resolution 682 x 2560 (2.5K) Pixels per inch 178
Point Pitch 0.007 mm Brightness 500 nights
Contrast ratio 1000:1 Angle 80 Degrees
Frequency of update 60 Hz Pixel Response Time 30 ms
Touch input Yes, 10-point multi-touch Input connections USB 2.0 connector, SATA power, DisplayPort
Powered by Nexus Yes, Nexus Touch
