CPU specifications
Number of cores – 10
Number of Performance-cores – 6
Number of Efficient-cores – 4
Number of threads – 16
Maximum turbo frequency – 4.60 GHz
Performance-core maximum turbo frequency – 4.60 GHz
Maximum Efficient-core Turbo Frequency – 3.30 GHz
Performance-core base frequency – 2.50 GHz
Efficient-core base frequency – 1.80 GHz
Cache – 20 MB Intel® Smart Cache
Total L2 cache – 9.5 MB
Processor base power – 65 W
Maximum turbo power – 154 W
Memory specifications
Maximum memory size (depends on memory type) – 128 GB
Memory types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Maximum number of memory channels – 2
Maximum memory bandwidth – 76.8 GB/s
Processor graphics
Processor graphics
‡
‡
Intel® 730 UHD Graphics
Graphics base frequency – 300 MHz
Maximum dynamic graphics frequency – 1.55 GHz
Graphics output – eDP 1.4b, DP 1.4a, HDMI 2.1
Execution units – 24
Maximum resolution (HDMI)‡ – 4096 x 2160 @ 60Hz
Maximum resolution (DP)‡ – 7680 x 4320 @ 60Hz
Maximum resolution (eDP – integrated flat panel)‡ – 5120 x 3200 @ 120Hz
DirectX* – 12 support
OpenGL support* – 4.5
OpenCL* support – 3.0
Multiformat codec engines – 1
Intel® Quick Sync Video – Yes
Intel® Clear Video HD Technology – Yes
Number of supported screens – 4
Expansion options
Direct Media Interface (DMI) Revision – 4.0
Maximum number of DMI lanes – 8
Scalability – 1S Only
PCI Express – 5.0 and 4.0 revision
PCI Express configurations Up to 1×16+4, 2×8+4
Maximum number of PCI Express lanes – 20
Package specifications
Compatible Sockets – FCLGA1700
